From the bike park to enduro tracks to steep singletrack shredding, this all-mountain bruiser has swagger to spare. The lightweight, super-stiff aluminum frame is long and low, and its Maestro suspension helps you float through the rough stuff.
This amped up version of the Reign enduro and all-mountain machine is made for riders who gravitate toward steep, rough and aggressive descents. It offers a longer travel 170mm fork and robust components that make it suitable for unforgiving terrain. The super strong and stiff ALUXX SL aluminum frame features updated geometry with a longer cockpit that’s designed to optimize its 27.5 wheels. The trunnion-mount Maestro rear suspension system offers 160mm of smooth, active travel and is bolstered by the new Advanced Forged Composite upper rocker arm, which is lighter and stronger than the previous aluminum design. If hammering through rock gardens and flying down steep descents is your idea of the perfect ride, then Reign SX is the machine for you.
KEY PERFORMANCE FACTORS
27.5 agility and control
- 27.5-inch wheels balance agility and control, giving you the ability to roll over rugged terrain, flick the bike at speed, change lines, and explode out of corners.
Latest suspension tech
- Updated Maestro rear suspension features a trunnion mount shock with a longer stroke and smoother feel. With 160mm of travel (and 170mm up front), it has the new Advanced Forged Composite upper rocker arm for increased stiffness and strength plus lower overall frame weight.
- The lightweight and stiff Advanced-grade composite frameset features updated enduro-style geometry, so you can ride aggressive descents and rail corners with confidence.
|Frame||ALUXX SL-Grade Aluminum, 160mm|
|Fork||RockShox Yari RC DebonAir, 180mm, Boost 15x110 Maxle Stealth, tapered, 46mm offset|
|Rear Shock||RockShox Super Deluxe Coil Select|
|Rims/Wheels||Giant DH 27.5 tubeless ready sleeve-joint rim, 27mm inner width|
|Hubs||Front: Giant Tracker Performance Boost 15 x 110mm, sealed bearing Rear: Giant Tracker Performance Boost 12 x 148mm, sealed bearing|
|Tires||Front: Maxxis Minion DHF 27.5x2.5 WT, folding , EXO, TR, Rear: Maxxis Minion DHRII 27.5x2.4 WT, folding, EXO, TR, tubeless|
|Crankset||Praxis Cadet, Giant custom design with MRP CS guide|
|Bottom Bracket||Praxis BB-90, press fit|
|Rear Derailleur||Shimano Deore|
|Cassette/Rear Cogs||Shimano HG400, 11 - 28|
|Handlebars||Giant Contact SL TR35, 800x35mm, 20mm rise|
|Stem||Giant Contact SL 35|
|Brake Levers||Shimano MT501|
|Brakes||Shimano MT520 Hydraulic Disc|
|Saddle||Giant Contact (neutral)|
|Seat Post||Giant Contact SL, zero offset, 30.9mm|
* Subject to change without notice.
|Gunmetal Black / Small||04712878455221||2001040104|
|Gunmetal Black / Medium||04712878455238||2001040105|
|Gunmetal Black / Large||04712878455245||2001040106|
|Gunmetal Black / X-Large||04712878455252||2001040107|
